3WPZ-1000 Self Propelled Sprayer
1. New appearance design based on the internationally renowned fashion elements of agricultural machinery.;
2. Brand new independent design, front and rear differential lock, high-end drive axle, adapt to various harsh environments;
Description
3WPZ-1000 self propelled sprayer main feature:
1. New appearance design based on the internationally renowned fashion elements of agricultural machinery.;
2. Brand new independent design, front and rear differential lock, high-end drive axle, adapt to various harsh environments;
3. After digital analysis, three-dimensional simulation and actual verification, the front and rear weight and center of gravity are optimally distributed;
4. Four-wheel drive, four-wheel steering;
5. The frame of the whole machine adopts manganese steel material, and adopts the car electrophoresis and then spray paint process.
3WPZ-1000 self propelled sprayer technical parameter:
S/N | Item | Unit | Specification |
3WPZ-1000A | |||
Machine dimension | Overall dimension | mm | 4850*2080*2950 |
Machine boom length | mm | 14500 | |
Lifting height of boom | mm | 500-1800 | |
Min. Ground clearance | mm | 1050 | |
Wheel base | mm | 2050 | |
Wheel tread | mm | 1800 | |
Cabin type | / | Simple type | |
Spray system | Machine work pressure | Mpa | 0.2-0.5 |
Medicine box capacity | L | 1000 | |
Medicine box material | / | Plastic | |
Mixing method of liquid medicine | / | Jet + reflux | |
Spraying width | mm | 18000 | |
Number of nozzles | pc | 40 | |
Nozzle style | / | Cone mist nozzle | |
Boom material | / | Aluminum alloy | |
Spray bar placement | / | Front placed | |
Liquid pump structure | / | Plunger pump | |
Power system | Engine mode | / | Diesel engine |
Engine structure type | / | 4 cylinders, in-line, water-cooled, four stroke | |
Rated power/speed | kW/(r/min) | 36.8/2400 | |
Working voltage | V | 24 | |
Walking system | Drive type | / | 4WD |
Steering type | / | 4WD | |
Trye type | / | Pneumatic tire | |
Tyre OD | mm | 1100 | |
Tyre width | mm | 120, tyre specification can be optional | |
Drive axle structure | / | Front and rear differential lock |
